Ignition Instructions:

The heater can be regulated to three different heat intensities: 1- LOW, 2- MEDIUM and 3- HIGH.

Ignition mode: piezo ignition.

1. Open the valve on the gas cylinder

1 and 1/2 turns.

2. Press down and turn the gas control knob to 1-LOW position and hold down for up to 10 seconds.

3. While still pressing down the gas control knob, press and depress the ignition button until the pilot light (at the bottom of the burner) ignites.

Continue to hold the gas control knob down for 10-15 seconds or until the ceramic plate lights

up. Upon releasing the gas control knob, if the pilot flame goes out, repeat the above operation.

4. Once the heater is lit at the 1-LOW setting, turning the control knob to 2- MEDIUM or 3-HIGH position will light the second and third panel respectively.

5. To turn off the heater, return the gas control knob to the OFF position and close the gas cylinder valve fully (clockwise).
