Description

Features
Simulated sinewave inverter
Wide input voltage range
12VDC available
Overload and short circuit protection
LCD display for comprehensive information CAPACITY
1200VA/ 720W INPUT Voltage
230 VAC Acceptable Voltage Range
90-280VAC Frequency
50 Hz/60 Hz (Auto sensing) OUTPUT
AC Voltage Regulation (Batt. Mode)
10% Efficiency (Peak)
82% Transfer Time
20 ms typical Waveform (Batt. Mode)
Simulated sine wave BATTERY & AC CHARGER
Battery Voltage
12 VDC Floating Charge Voltage<...br />13.7 VDC 2% Low Battery Alarm Voltage
10.2Vdc 2% Shutdown Voltage
9.9Vdc 2% Overcharge Protection
15.0Vdc 2% PROTECTION Full Protection
Overload, short circuit and polarity reserve protection PHYSICAL Dimension, D X W X H (mm)
300 x 360 x 88 Net Weight (kgs)
4.6 OPERATING ENVIRONMENT Humidity
0 to 90% Relative Humidity (Non-condensing) Operating Temperature
0 C to 40 C Storage Temperature
-15 C to 50 C What’s in the box
1 x 1200VA Inverter with Power Cable and Battery Cable
